Surveillance camera Dahua IPC HFW1230T-ZS-2812-S5, Bullet IP 2MP CMOS 1 / 2.7 ”, 2.8-12mm motorized zoom, IR50m, IP67

Bullet IP camera Dahua IPC-HFW1230T-ZS-2812-S5, 2MP CMOS 1 / 2.7inch, 2.8-12mm varifocal zoom lens motor, IR50m, motion detection, IP67, metal housing
Chamber Dahua CPI-HFW1230T-ZS-2812-S5 is equipped with a CMOS image sensor progressive scan 1 / 2.7 “2MP , which will lets you capture videos at a resolution of 2 MPx . Several correction functions available, including DWDR, 3DNR, ensure excellent image quality. modern compression system H.265 + signal is transmitted room to occupy less space on the recording medium (eg card HDD or microSD), which translates into an effective protection and a longer data retention. In addition, objective type Motozoom allows external adjustment of the distance of the level of the focal length and also automatically adjusts the sharpness. the advantage of the device is a slot built-in microSD card (256 GB). IPC-HFW1230T-ZS-2812-S5 is characterized by a high degree of resistance to the conditions met eorologice negative ( IP67 ).
assembly required accessories are not included, you can choose from HERE.

Camera Specifications:

Sensor
progressive scan CMOS 1 / 2.7 “2MP

Resolution
2Mpx 1920 x 1080 pixels

RAM / ROM
64MB / 16MB

Scanning System
Progressive

Minimum illumination
0.008 Lux / F1.7

Illuminating

2 LED IR

Control illuminator
Auto / Manual

Goal

Type
Varifocal (Motozoom)

assembly
φ14

Focal Length
2.8 ~ 12mm (F1.5)

angle view
H: 106 ° -33 °
V: 56 ° ~ 19 °
D: 127 ° ~ 38 °

focus adjustment
Autofocus

Macro mode
0.8 m (2.6 ft)

Coverage LIKE
Detection: W – 44m, T – 153,1m
Note: W – 17,6m, T – 61,2m
Recognition: W – 8,8m, T – 30,6m
Detection: W – 4,4m, T – 15,3m

Images

Video compression
H.265 / H.264 / H.264B
MJPEG (secondary stream)

Smart Codec
Yes (H.265 + / H.264 +)

Number of simultaneous video streams
2

resolution processing
1080p – 2Mpx (1920×1080) / 1,3Mpx (1280×960) / 720p (1280×720) / D1 (704×576 / 704×480) / VGA (640×480) / CIF (352×288 / 352×240)

Control transmission rate
CBR / VBR

Bitrate
32kbps ~ 6144Kbps (H.264)
12Kbps ~ 7424Kbps (H.265)

Day night
Auto (ICR) / Color / BW

Get control
Auto (AGC) / Manual

Compensation fund
DWDR

white balance
Auto (AWB) / Natural / streetlights / Outdoor / Manual / Region

Noise Reduction
3D DNR

Rotate image
0 °, 90 °, 180 °, 270 ° (holder 90 °, 270 ° resolution 2MP)

Smart features

Trigger Event
Motion detection, handling, lack of SD card / overflow / error, loss of connection, IP address conflict, unauthorized access, fault voltage

Interface

Ethernet
1x RJ45 10/100 Base-T

Power
1 x socket 5.5 / 2.1 cable

memory
1 x microSD card slot / microSD / microSDXC up to 256 GB

Network

Supported protocols
IPv4, IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, SMTP, FTP, DHCP, DNS, NTP, Multicast

Compliance with the standard
ONVIF (profit), CGI, Genetec, P2P

Users online
User 6

Archiving network
Card FTP / Cloud Dahua / MicroSD

Building
Metal

class tightness
IP67

Power

DC 12V (± 30%), the power supply is not included
DC 48V PoE (802.3af Class 0)

Power consumption
& lt; 6,2W

humidity
0 ~ 95%

working temperature
-30 ° C ~ + 60 ° C

Weight
860g (1.9Ib)

Size (width / length)
Ø90,4×244,1mm (Ø3,6 “x 9.6”)
