HiLook TCP/IP Video Intercom Monitor, 7″ Touchscreen, 2.4GHz Wi-Fi, PoE, Audio VI-H460WD

The HiLook VI-H460WD video intercom monitor delivers a high-quality viewing experience with its 7-inch capacitive touchscreen and 1024 × 600 resolution, providing clear and detailed images. Equipped with an omnidirectional microphone and built-in speaker, it enables clear two-way communication, allowing you to respond to visitors easily.

Technical Specifications HiLook Video Intercom Monitor VI-H460WD:

• Operating System: Linux

• ROM: 32 MB

• RAM: 128 MB

• Processor: High-performance built-in processor

• Screen Size: 7 inches

• Display Type: Color TFT

• Touchscreen: Capacitive

• Resolution: 1024 × 600

• Audio Input: 1 built-in omnidirectional microphone

• Audio Output: 1 built-in speaker

• Audio Compression: G.711U, G.711A

• Audio Bitrate: 64 Kbps

• Audio Features: Noise suppression and echo cancellation

• Message Storage: Up to 200 captured images (with TF card), 200 alarm recordings

• Network Camera Capacity: 16

• Indoor Extension Capacity: 16

• Intercom Support: 2 analog intercoms, 15 network intercoms

• Network Protocols: TCP/IP, SIP, RTSP

• Wi-Fi: 2.4 GHz (IEEE 802.11b/g/n)

• Network Interface: 1 × RJ-45 10/100 Mbps, auto-adaptive

• RS-485 Interface: 1, half-duplex

• TF Card Support: Up to 128 GB

• Alarm Inputs: 2

• Alarm Outputs: 2

• Door Lock Control: 2 relays, max. 30 VDC, 0.3 A

• Four-Wire Interface: 2

• Installation: Wall-mounted or desktop

• Net Weight: 340 g (0.75 lb)

• Gross Weight: 709 g (1.56 lb)

• Operating Temperature: -10 C to 55 C (14 F to 122 F)

• Operating Humidity: 10% to 90% (non-condensing)

• Dimensions (L × H × D): 200 × 140 × 23.6 mm (7.9″ × 5.5″ × 0.9″)

• Power Supply: 12 VDC, PoE IEEE 802.3af

• Power Consumption: ≤ 5 W

• Application Environment: Indoor

The monitor connects via 2.4 GHz Wi-Fi and integrates with the Hik-Connect mobile app, giving full control over access. You can make calls and grant access remotely from your smartphone, with instant push notifications for any unexpected events, enhancing home security.

Additionally, the PoE (Power over Ethernet) support allows data and power to be transmitted through a single cable, reducing installation time and costs. The VI-H460WD combines advanced technology with a user-friendly design, making it a modern and efficient solution for any home.
