The Bridge has the following main features:
- High performance with cost efficiency;
- One-touch connection;
- Easy-to-use tool for location analysis;
- Alignment tool;
- Spectrum scanning and connection optimization;
- Complete management in the Cloud;
- Wind resistance with speeds up to 220.32 km/h.
Technical specifications:
- Manufacturer Ruijie
- Network interface 1 x RJ45 10/100 Mbps
- Frequency 5 GHz (2.4 GHz for management)
- Wi-Fi standards 802.11 b/g/n/a/ac
- Antenna 23 dBi, 9(H), 9(V)
- Transfer speed 867 Mbps
- MTBF > 400,000 hours
- Cloud Management APP/Web
- 24V passive PoE power supply
- Max consumption 9W
- Dimensions 368.5mm x 271mm
- Operating temperature -40C ~ +70C, IP65
- ESD Protection Tolerance: ±24 kV Contact/Air
- 6 kV surge protection
