Switch 4 PoE ports TP-Link – TL-SG1008P
Specifications
- Standards: IEEE 802.3i/u/ab/x/af, 802.1p
- Port: 8 x 10/100/1000Mbps RJ45
- PoE port: 4 ports, 55W total
- 10BASE-T: UTP cable cat. 3, 4, 5 (max 100 m)
- 100BASE-TX: UTP cable cat. 5, 5e (max 100 m)
- 1000BASE-T: UTP cable cat. 5, 5e or above (max 100 m)
- Transmission method: Store-And-Forward
- Switching capacity: 16 Gbps
- MAC address: 4K, auto-learning, auto-aging
- Functions: Plug&Play, PoE port prioritization on overload
- AUTO Negotiation, AUTO MDI/MDIX, Flow Control
- LED indicator
- Housing: metallic
- Certification: FCC, CE
- External power supply: external adapter 48 VDC/1.25 A
- Operating temperature: 0C – 40C
- Humidity: 10% – 90% without condensation
- Size: 171 x 98 x 27 mm
DESCRIPTION
TP-Link TL-SG1008P is an easy-to-install (Plug&Play) 8-port 10/100Mbps network switch that includes 4 PoE (Power over Ethernet) ports – ports 1, 2, 3 and 4.
This model is compatible with IEEE 802.3af compliant PD (Powered Devices), providing each PoE port with a capacity of up to 15.4 W, with a maximum total of 55 W for all PoE ports. The switch has a prioritization function, which protects the system in case of energy overload.
If PoE power consumption reaches or exceeds 55W, the switch will prioritize ports and power down a port based on its importance (ports 1, 2, and 3 having equal priority, and all above port 4). This mechanism ensures efficient power distribution and protects the connected equipment.
