2-camera video surveillance kit
Video surveillance kit 2 professional cameras 2 MP 1080P full hd 20m infrared, 4-channel DVR, mobile software included
2-camera video surveillance kit contains:
– 2 x External surveillance camera AHD 1080P full hd 20m IR ZAN30W-200
– DVR ROV504 5MP-N 4 channel Rovision 6 in 1 compression H265
Technical specifications
Surveillance camera resolution | Full HD 2-2.4 MP |
Video camera technology | AHD |
Camera type | Interior, Exterior |
Number of cameras / kit | 2 |
Type of surveillance kit | interior, exterior |
Lens type | fix |
IR – Infrared | 20m |
Number of DVR channels | 4 |
DVR resolution | 1080P |
Other camera functions | Motion detection |
Details 2-camera video surveillance kit:
ZAN30W-200 is a 1080p full hd outdoor surveillance camera with fixed lens, 20m infrared and 24 led lens, AHD technology.
Built on AHD technology, the ZAN30W-200 video surveillance camera is recommended for outdoor installation. It is in IP66 weather protection class , being able to operate at temperatures ranging between -20 and +50 degrees Celsius.
sensors
The camera includes a 1 / 2.9 ” ccd sensor Aptina FH8536 (V30E) + AR0337, the resolution being 1920 × 1080 . It can transmit up to a maximum distance of 500m.
The camera comes with a 3.6 mm fixed lens, which is useful for areas where objects are far away from the camera. This, together with the special construction with metallic plastic housing, recommends the camera for monitoring the entrances in institutions or blocks, parking lots, shopping centers, garages or office buildings.
In the construction of the camera we notice 24 LEDs that increase the performance of the camera during the night. The IR sensor allows the visibility of objects in the dark up to 20m .
Functions
The camera also comes with Backlight compensation function , it can compensate for backlighting, optimizing the automatic exposure of the camera. The camera also has an IR-Cut filter function , meaning it offers color images during the day. With daylight dimming, the camera will automatically switch to night mode using infrared light to provide high-quality black-and-white images.
We also notice the white balance function for the camera that allows you to adjust the colors so that the colors look as natural as possible.
The list of functions continues with the presence sensor included , which increases the versatility of the camera.
A 12V +/- 10%, 450mA power supply is required for the operation of the monitoring camera. The power supply is not included, but the extremely affordable price makes the camera a safe option for many limited budgets and simple monitoring scenarios.
Specifications:
- ZAN30W-200 Weatherproof full hd outdoor surveillance camera
- AHD technology
- sensor 1 / 2.9 ″ ccd Aptina FH8536 (V30E) + AR0337
- 1080P / 2MP resolution
- 1920 × 1080
- minimum lighting 0.01Lux
- transmission distance up to 500 m
- fixed lens, 3.6 mm
- metallic plastic housing
- leds 24 pcs
- infrared distance 20 m
- presence sensor
- white balance
- Backlight compensation
- IR-Cut Filter
- IP66
- operating temperature -20C + 50C
- power supply 12V ± 10%, 450mA
- power supply is not included
- Dimensions 82mmx251mm (L)
- Weight 461g
DVR ROV504 5MP-N on AHD technology 4 channels Rovision 6 in 1 H.265 compression. Works with any AHD camera up to 5 megapixels.
- Intuitive use by using a graphical interface with icons
- 25fps real-time viewing on each channel at 1080P and 5MP-N resolution on AHD cameras on all channels
- 1080P / 14fps recording, 720P / 25fps, 960H / 25fps
- H.265X video compression (reduces file size and allows recording for longer periods)
- HDD storage (up to 6TB) NOT INCLUDED
- Own software for live viewing on the phone through the Cloud using the application downloaded from the Phone Application Store
- VGA and HDMI ports for connection to any TV / monitor
- USB ports for peripherals and for quick USB backup
- RJ45 port for internet connection
Contain:
- Mouse
- 12V / 2A power supply
- HDD mounting screws
- Installation manual
General
- 12V / 2.5A power supply
- Power consumption <15W (without HDD)
- Working environment: Temperature: 0 ℃ – + 55 ℃ , Humidity: 10% —90% , Atm: 86kpa — 106kpa
- Size 233x210x45 mm
- Weight 510 gr (without HDD)
Works with any AHD camera up to 5 megapixels
