General Features
Outdoor Use
Format Bullet
Water/dust protection IP66
Vandal-proof IK10
Card storage microSDHC / microSDXC SD card slot
Power supply POE IEEE 802.3af / 802.3 at Type 1, Class 3
12 VDC ±30%
Operating temperature -30o
Dimensions 101.5 x 307 mm
Weight 1630 g
Camera IP
PoE Yes
Lens type Varifocal
Varifocal lens 3.2-10 mm
Motorized zoom Yes
Resolution 2 MP
Effective resolution 1920 x 1080 pixels
Sensor type CMOS
Sensor size 1/2.8 inch
Video compression H.265; H.264; M- JPEG
Night recording Yes
WDR 120 dB
Motion detection Yes
Shutter speed Automatic Electronic Shutter (AES) , Fixed (1/25[30] to 1/15000), selectable Default shutter
S/N Ratio >55 dB
Privacy Mask Eight independent areas, fully programmable
Frame rate 1 to 30 fps
Built-in microphone No
microSDHC / microSDXC SD card slot
Protocols
IPv4, IPv6, UDP, TCP, HTTP, HTTPS, RTP/RTCP, IGMP V2/V3, ICMP, ICMPv6, RTSP, FTP, ARP, DHCP, APIPA (Auto-IP, link local address), NTP (SNTP), SNMP (V1, V3, MIB-II), 802.1x, DNS, DNSv6, DDNS (DynDNS.org, selfHOST.de, noip.com), SMTP, iSCSI, UPnP (SSDP), DiffServ (QoS), LLDP, SOAP, Dropbox™, CHAP, digest authentication
ONVIF ONVIF Profile S; ONVIF Profile G; ONVIF Profile T
Alarm
Rule based alarms and tracking, Line crossing, Enter / leave field, Follow route, Loitering, Idle / removed object, People counting, Crowd density estimation, 3D tracking
Mifare 13.56MHz card reader, USB interface SEB-USBREADER-M
Proximity tag with EM4100 chip (125KHz) CST-EM125-B
