Distinguishing DS-2CD1143G0 him
Resolution: 4 MP (2688 x 1520)
Lens: 2.8 mm / 100 °
Video compression H.265 + / H.265 / H.264 + / H.264 / MJPEG
video processing functions: 3D-DNR DWDR, BLC
Access system remote applet HIK-Connect
Regions of interest (ROI)
Mechanical switch IR filter
Class sealing: IP67
Power: 12 VDC or PoE (802.3af)
Camera Hikvision DS-2CD1143G0-I is dedicated to IP surveillance systems. Ceiling room was equipped with a sensor with a resolution of 4 MP 1/3 “CMOS video that plays excellent coverage even in poor lighting conditions. With IR illuminator with coverage distance of max. 30 m, the camera works even in complete darkness. the lenses incorporated 2.8 mm play an aperture of 100 °. position the degree of protection IP-67 protects the electronics from adverse environmental conditions. the camera can be powered by a source 12 VDC or with the PoE ( 802.af).
1/3 “Progressive Scan CMOS
@ 0.028 lx (F2.0, AGC ON)
0 W in IR
2.8 mm @ F2.0 / 100 a
2560 x 1440 pixels
20 fps @ 2560 x 1440
25 fps at res. lower
+ H.265 / H.265 / H.264 + / H.264 / MJPEG
number video streams
data rate range
32 kbps – 8 Mbps
max. 30 m
3D-DNR DWDR, BLC
Mechanical switch IR filter
Auto / Preset
Motion detection, video tampering
Intelligent image analysis
NAS (NFS / SMB / CIFS), FTP (screenshots)
RJ-45 10 / 100Base-T
TCP / IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP
PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
ONVIF (profile S, G), ISAPI
and IP protection class IK
12 VDC ± 25%
IEEE 802.3af PoE
Max. 5 W
temperature range. running
-30 ° C … + 60 ° C
Φ111 × 82 mm
The camera belongs to the new series IP Easy Lite characterized by high performance at an affordable price. Series supports motion detection and detection of camera tampering. Rooms in this series play and way corridor and can define a Region of Interest (ROI).
video compression H.265 + / H.265
H.265 + / H.265 – compression rate with the same quality optimized H.264 video compression
Chamber implements several methods of video compression, H.265 +, H.265, H.264 +, H.264, MJPEG. Compared with H.264, H.265 can reduce by half the flow of data, which translates into savings of disk space proportional or extended retention time. H.265 + and H.264 + systems are standards-based Hikvision original and optimized for CCTV applications. These decreases further flows typical video surveillance scenarios. Using advanced video compression algorithms, the camera can be used in IP CCTV systems based NVRs implementing modern H.265 standard (Series DS-76/77 / 96NI-I / K supports H.265 +, H.265 , H.264 +, H.264). Of course, the camera can work with older models that support H.264 (Series DS-76 / 77NI-E supports H.264 +, H.264).
iVMS 4200 client applet allows users to administrize Hikvision equipment within IP networks. Applet management and the administration of an NVR / DVR, IP camera or the like (the hybrid systems). IVMS4200 utility can remotely manage up to max. 256 equipment, with a max. 4 monitors. A monitor can display max. 64 rooms. In addition to system configuration and real-time monitoring, the utility can be used to play records notifications, bidirectional audio transmission or creation of installation plans for different environments and situations (e-maps).
View of control panel applet iVMS-4200
Hik- Connect is a mobile applet designed smartphones running operating systems such as Android or iOS. It can be used to monitor real-time images from the DVR, NVR or IP camera via Wi-Fi, 2G or 3G, as well as playback of recorded video. Applet connects devices by IP addresses and / or P2P Cloud.
The main screen of the applet HIK-Connect screen for real-time preview
Screen applet HIK-Connect to view cameras in real time
Working in the Cloud
HIK-connect is also a network service for Hikvision equipment. The service is based on processing data in Cloud and integrates the following functions:
Remote access via the cloud – access to equipment without needing an external IP address. Required only basic network settings. Install applet on a PC or smart phone device will connect via Cloud online P2P
Server DDNS – DDNS assigns a fixed domain name to a dynamic IP addresses (Dynamic DDNS). This function is useful when the ISP does not provide the user with a fixed IP address. Ed for use DDNS need a public IP address and allowing access from an external network ports assigned to the NVR (http server and thus 8000 and 80). The connection is possible via a web browser applet client on a PC or smart phone.
applet LAN IP surveillance systems organization
SADP (Search Active Device Protocol) is a free and easy to use search Hikvision IP cameras and DVRs / NVRs Hikvision local network. Search software can also be used to modify network parameters of Hikvision devices, including changing passwords or default passwords recovery. Detailed information on the software and its use are contained in SADP – application management Hikvision surveillance equipment.
Effective protection against vandalism
European Standard EN 62262 classifies mechanical strength of equipment IK degrees. Testing for compliance with IK classes is according to norm EN 62262: 2003.
Camera complies impact resistance class IK10
Hammer in free fall – height: weight …
… … 20 cm 0.5 kg
… … 40 cm 0.5 kg
… 29.5 cm 1.7 kg
20 cm 5 kg … ……
40 cm 5 kg … ……
