Hybrid solar inverter 12V 500W Kemot PROsolar 800 – URZ3416

Use of solar inverters

Direct input to solar panels means that these devices use solar energy to power receivers connected to the existing electrical network. The solar inverter will also be suitable for powering electrical equipment that requires an alternating voltage of 230 V and, as an emergency source, will ensure the trouble-free operation of devices that require continuous power. KEMOT solar inverters with a power of approximately 500 W are suitable, for example, for central heating pumps, alarm systems, monitoring. In turn, higher power devices can be used to power refrigerators, kettles and other more demanding devices.

Two modes of operation

KEMOT solar inverters are an additional source of electrical energy obtained from solar energy, which in the event of a power cut you can use to support all the devices that require constant energy from the network in your home. The important thing is that the device needs a maximum of 6 milliseconds to switch between the individual modes.

PV priority mode

1. During the day (sunlight is sufficient) and the devices are also connected to the power grid: the photovoltaic cells will power the external devices, at the same time charging the battery (the grid power supply will be in standby mode at this moment).
   2. In the evening, the system will power the devices from the battery until the low voltage protection is activated; the system will automatically enter AC power mode and charge the battery to a specified level to provide emergency power. The battery will be fully charged by the photovoltaic cell once the photovoltaic power is restored.

AC priority mode

1. Mains power is available: the devices will be powered from the mains. The photovoltaic cells will recharge the battery.
   2. In case of exceeding the voltage range or network interruption: the connected devices will be powered by the battery and photovoltaic cells to maintain the continuity of the power supply. If the solar energy is unavailable or insufficient, the connected devices will be powered only from the battery.

Pure sine wave form

Solar inverters of the PROsolar series are suitable for all devices that are extremely sensitive to the smallest changes in the shape of the voltage. Their advantage is a pure sinusoidal waveform of the output voltage (load supply), thanks to which the devices ensure a stable operation, preventing the effect of overheating of inductive loads. Together with the battery it constitutes a complete guaranteed 230 VAC supply device.
