Fire cable JY(St)Y, 2x2x08 shielded, roll 100m MEK-2X2X08

Availability:

In stock


Without VAT

43,05

In stock

Bank transfer, Invoice with VAT or no VAT(VIES confirmation), VISA card, Mastercard credit card or cash on delivery. You can pay for your order comfortable cash on delivery in Bulgaria, Hungary, Greece, Poland, Slovakia, Slovenia, Czech Republic and Croatia. Easy Returns 14 days for return items. We ship from Europe. Shipping cost is starting at 10.64 euros without vat depending on the country and weight. Free shipping on orders over €500, oversized deliveries may incur additional shipping charges depending on product weight and dimensions
  • Flame resistant, in accordance with the EN 60332-1-2 standard
  • Max. resistance loop 73.20 Ω / km at 20°C
  • Wire colors according to VDE 0815: red/blue, yellow/grey
  • Operating temperature -30°C to +70°C
  • Nominal operating voltage 300 V
  • Test voltage 800V (1min/50Hz)
  • Insulation resistance min. 100MΩ / km
  • Capacity at 800 Hz max. 100nF/km
  • Imbalance capacity (unbalanced) 300pF/100 m
  • Minimum radius of curvature approx. 10 x cable diameter

Model / manufacturer: MEKAS KABLO
No. of threads: 4
Wire diameter: 0.8 mm
Conductor: twisted in pairs wrapped in AL-PES tape
Sheath: PVC
Wire colors: red / blue gray / yellow
Packaging: 100m roll (price per roll)
Weight: 5.8 Kg/roll
Coat color: Red

SKU: MEK-2X2X08 Categories: ,
Weight 5,800000 kg
Dimensions 0,00 × 0,00 × 0,00 cm
