DVR Pentabrid 4 channels Rovision, 1080N H.265+, Audio throught coaxial
Availability:
Out of stock
Without VAT
€28,55
Out of stock
DVR Pentabrid 4 channels Rovision, 1080N H.265+
- H.265 + / H.264 video compression that reduces video bit rate by up to 90% to reduce storage space required for video recordings
- Supports cameras with HDCVI / AHD / TVI / CVBS / IP technology automatically detecting the camera signal without manual configurations
- Supports HDD with a capacity of up to 6TB
- View on Android or iOS phone through the Rovision Connect application available in the Play Store and App Store
- Supports 1080P Lite resolution on all channels
- Transmits 720p to 1200 meters on coaxial cable
- Dimensions: 200 x 200 x 45 mm
- Current consumption without 8W HDD
- Up to 6 IP cameras can be connected
- Network interface 1, RJ45 10 / M100M
Rovision Connect mobile application
You can watch live, but also the recordings from your home or commercial space remotely through the direct application on your phone or tablet.
The Rovision Connect application that offers you for free to be able to view images remotely from any device you want, if you have internet at your location.
(Found on PlayStore for Android and App Store for iOS).
Technical specifications
| DVR RO7104 | |
| Analog Video Input | 4 channels BNC |
| Encoding Resolutin | When 1080p Lite mode its on: 1080p lite/720p/WD1/4CIF/VGA/CIF
When 1080p Lite mode its off: 720p/WD1/4CIF/VGA/CIF |
| HDMI/VGA video output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Video Compresions | H.264+/H.264 |
| Recoding resolution | TURBO HD 1080p25, 1080p30, 720p25, 720p30
HDCVI 1080p25, 1080p30, 720p25, 720p30 CVBS 1080p25, 1080p30, 720p25, 720p30 |
| Recording rate | Main Stream: 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Secondary Stream : 2CIF@6fps; CIF/QVGA/QCIF@ 25fps (P)/30fps (N) |
| Video Bit Rate | 32 Kbps pana la 4 Mbps |
| Audio | Audi compresion G.711u
Audio Bit Rate 64Kbps Input 1-ch, RCA (2.0 Vp-p, 1 KΩ) Output 1-ch, RCA (Linear, 1 KΩ) |
| Auxiliar Interface | 1.0 Sata port that supports HDD up to 6TB
2x USB 2.0 |
| Overview | |
| Consumption | 8W |
| Working temps | From -10 up to +55 º C |
| Humidity | From 10% to 90% |
| Dimensions | 265 × 225 × 48 mm |
| Wight | 0.8 KG without HDD |
| Cartifications | FCC Part 15 Subpart B, ANSI C63.4-2014 CE EN50130-4, EN 61000-3-2, EN 61000-3-3 |
| Internet protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Network | 1, RJ45 10M/100M self-adaptive Ethernet interface |
| Meniu languege | English, changeable in any language |
| Porturi | BNC |
|---|---|
| Producatori | Rovision |
| Tip produs | DVR |
| Numar canale | 4 |
| Rezolutie | HD+1080Lite |
DVR si NVR |
|
| Manufacturer | Rovision |
| Number of channels | 4 |
| Resolution | HD+1080Lite |
| Resolution | |
| Number of channels | 4 |
| Manufacturer | Rovision |
