Dahua Surveillance System 2 Outdoor Cameras 5MP, 4-Channel XVR DVR, 5MP

Dahua Surveillance System 2 Outdoor Cameras 5MP, 4-Channel XVR DVR, 5MP

The system includes:

• 2× Outdoor surveillance cameras, 5MP, Dahua

• 1× Dahua DVR XVR5104HS-I3, 4-channel XVR

Outdoor Surveillance Camera, 5MP, Dahua

The Dahua Bullet HAC-HFW1500C-0280B-S2 surveillance camera is an excellent solution for protecting both indoor and outdoor spaces, featuring IP67 protection against external factors. Thanks to the 1/2.7-inch CMOS sensor and 5 Megapixel resolution, it delivers high-quality recordings.

The camera is equipped with three high-performance IR LEDs, providing clear night-time images at distances of up to 30 m. Smart IR technology helps balance illumination in black-and-white mode.

The fixed 2.8 mm lens offers a wide viewing angle:

• Diagonal: 132

• Horizontal: 111

• Vertical: 58

Additional details:

• Plastic housing

• Operating temperature: 40 C to +60 C

• Dimensions: 161.3 mm × 69.7 mm × 70.0 mm

• Weight: 0.19 kg

• Frame rate: 5M 25 FPS

• Power supply: 12 V DC

• Manufacturer: Dahua

Dahua DVR XVR5104HS-I3, 4-Channel XVR

The DVR (Digital Video Recorder) is a digital device that stores recordings from analog and IP surveillance cameras. Part of Dahua’s AI series, the XVR5104HS-I3 features 4 channels and supports recording at 5 MP resolution. It also supports up to 6 IP channels with resolutions of up to 6 MP.

For storage, the XVR5104HS-I3 allows the use of an HDD with a capacity of up to 6 TB and offers backup via USB or directly over the network. The supported video compression standard is H.265+.

Audio / Video

• Supported technologies: HDCVI / AHD / TVI / CVBS / IP

• Analog video inputs: 4 channels

• IP video inputs: 4 + 2 channels, up to 6 MP/channel

• Video outputs: 1× HDMI, 1× VGA

• Playback resolution: 1920 × 1080; 1280 × 1024; 1280 × 720

• Audio inputs/outputs: 1/1, RCA

• Two-way communication: via audio input/output (RCA)

Supported camera types:

• HDCVI cameras: 5MP, 4MP, 1080p @ 25/30 fps, 720p @ 50/60 fps, 720p @ 25/30 fps

• AHD cameras: 5MP, 4MP, 1080p @ 25/30 fps, 720p @ 25/30 fps

• TVI cameras: 5MP, 4MP, 1080p @ 25/30 fps, 720p @ 25/30 fps

Recording

• Recording resolution: 5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF

• Frame rate:

  • Main stream: 5M-N (110 fps); 4M-N/1080p (115 fps); 1080N/720p/960H/D1/CIF (125/30 fps)

  • Sub-stream: D1/CIF (115 fps)

• Recording modes: Continuous, Manual, Scheduled, Motion Detection, Video Loss, Alarm, Stop

• Recording interval: 160 min, Pre-record 130 s, Post-record 10300 s

• Video compression: AI Coding / H.265+ / H.265 / H.264+ / H.264

• Bit rate: 32 kbps 6144 kbps / channel

• Audio compression: G.711A; G.711U; PCM

• Audio bit rate: 64 kbps/channel

Network

• Interface: 1× RJ-45 port (100 Mbps)

• Network protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, IP Search (Dahua IP cameras, DVRs, NVRs, etc.)

• Simultaneous users: 128

• Smartphone compatibility: iPhone, iPad, Android

• Interoperability: ONVIF 16.12, CGI

Storage

• HDD: 1× SATA port (up to 6 TB)

Perimeter Protection / Face Detection / SMD Plus

• Perimeter protection: 1 channel, 10 IVS rules per channel

• Secondary human/vehicle recognition for tripwire and intrusion

• AI Search: target classification (human / vehicle)

• Face recognition: processing up to 8 images/second

• 1 video stream channel for face recognition (analog cameras only)

• AI Search: up to 8 simultaneous images, similarity threshold adjustable per image

• “Stranger” mode: detection of unknown faces (not in the device database), adjustable similarity threshold

• Database management: up to 10 databases, 10, 000 facial images total

• Name, gender, date of birth, address, ID type and number, country and region can be added to each image

• Each database can be applied independently to video channels

• Trigger events: buzzer, voice prompts, email, snapshot, recording, alarm output, PTZ activation, etc.

• SMD Plus: 4 channels

• AI Search: target-based search (human, vehicle)

Auxiliary Interfaces

• USB: 2× USB 2.0 ports

• RS-485: 1 port, PTZ control

Special Functions

• Features: IoT, POS

• Video detection: motion detection, 396 (22 × 18) detection zones, video loss, tampering

• Playback functions: Play, Pause, Stop, Rewind, Fast Forward, Slow Play, Next/Previous File, Next/Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom

• Backup mode: USB, Network

• Playback: 1/4

• Search mode: Time/Date, Alarm, Motion Detection (MD), Exact Search

General Characteristics

• Operating temperature: 10 C to +45 C

• Power supply: DC 12 V / 1.5 A

• Power consumption: <4 W (without HDD)

• Dimensions: 260 mm × 238 mm × 48 mm

• Form factor: Compact 1U

• Weight: 840 g
